Link arm 1-leaf
TS 2100 V BC * Overhead door closer with link arm for single leaf doors with a leaf width up to 1250 mm
- Variable closing force of EN3, EN4 or EN5 due to offset installation
- Can be used for right and left hand doors without conversion
- Integrated back check, slows down doors that are thrown open forcefully
- Hydraulic latching action which accelerates the door shortly before it is closed
- Closing speed can be individually adjusted
- Approved by the GEZE Laboratory for ambient temperatures down to -40 °C
Application Areas
- Right and left single-action doors
- Single-action doors up to 1250 mm leaf width
- Door leaf installation hinge side and transom installation opposite hinge side
- Door leaf installation opposite hinge side in parallel arm installation possible
- Can be used with low ambient temperatures
Technical data
| TS 2100 V BC | |
| Closing force in accordance with EN 1154 | EN 3/4/5 |
| Barrier-free in accordance with DIN 18040 up to leaf width (max.) in mm | 1100 mm |
| Leaf width (max.) | 1250 mm |
| Type of installation | Door leaf installation hinge side, Door leaf installation opposite hinge side, Transom installation opposite hinge side |
| Opening angle (max.) | 180 ° |
| Closing force adjustable | Yes, via installation |
| Adjustable closing speed | Yes |
| Latching action adjustable | Yes, via valve |
| Back check integrated | hydraulically fixed |
| Position of closing force adjustment | Mounting position |
| Hold-open function | Optional |
Downloads
Variants & Accessories
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
