Perlan

Perlan 140 SoftStop, damped on both sides * Perlan 140 with SoftStopDuo damped on both sides with retraction

Technical data

Perlan 140 SoftStop, damped on both sides
Leaf material Wood
Leaf weight (max.) 80 kg
Number of leaves 1-leaf, 2-leaf
Leaf width (min.) 750 mm
Leaf width (max.) 1700 mm
Track geometry straight
Type of installation Wall, Ceiling
DIN direction left / right
Duosync No
draw-in damping two-sided
