ECdrive

GX 100 * Automatic linear sliding door drive for doors with up to 100 kg leaf weight

GX 100
  • Single and double leaf sliding door systems
  • Opening widths from 700 to 3000 mm possible
  • For doors up to 100 kg leaf weight per leaf
Contact us

Application Areas

  • Designer guide rails with dampening rubber strip ensure smooth and quiet operation
  • Operation and parameter setting for the DCU via Bluetooth over WeChat
  • Quick and easy installation thanks to modular design
  • Fall protection version of the roller carriages
  • Self-adjusting roller carriage
  • Standard conformity: GB34616-2017 and JG305-2011
  • Two pairs of photoelectric barriers optionally available
  • Tested on over 100000 test cycles

Technical data

GX 100
Height 125 mm
Depth 86 mm
Clear passage height 3000 mm
Service temperature -20 - 50 °C
IP rating IP20
Power consumption 150 W
Opening speed (max.) 0.5 m/s
Closing speed (max.) 0.5 m/s
Hold-open time 0.5 s - 60 s
Holding force (max.) 150 N
Self-learning Yes
Mode of operation Night, Permanently open, Automatic
Type of function Access control
Automatic reversing Yes
Pharmacy opening Yes
Interlocking door system function Yes
